Product Details:
|
| Material: | Q355B | Colour: | Custom |
|---|---|---|---|
| Warranty: | 1 Year | After-sales Service Provided: | Online Support |
| Bucket Capacity: | 0.4-0.5CBM | Boom Angle: | 45-90 Degrees |
| Controls: | Hydraulic | Product Name: | Long Reach Excavator Booms |
| Highlight: | 0.5CBM Mini Excavator Extendable Arm,Q355B Mini Excavator Extendable Arm,Kobelco Long Reach Excavator Booms |
||
ZH Excavator Attachment Catalog-Nina.pdf
The video shows of dipper arm on a digger
Product advantage of long excavator boom and arm:
01 Use Q355B material,
02 Adopts precision steel pipeline
03 Adopt alloy copper sleeve big arm base
04 Two layers groove welded to ensure
05 Double quality inspection before leaving
06 The tolerance of position size within 1 mm
07 Angle of boom and arm can reach 163°
The specification of excavator long reach attachment
| Excavator Ton | Total Length(mm) | (A)Boom(mm) | (B)Arm(mm) | Maximum Digging Radius(mm) | Maximum Digging Depth(mm) | Maximum Unloading Height(mm) | Maximum Digging Height(mm) | Bucket Volume(cbm) | Cylinder(ton) |
| 11-15T | 13000 | 7250 | 5750 | 11200 | 9000 | 7550 | 9350 | 0.15-0.3 | 12T |
| 20-25T | 15400 | 8220 | 7180 | 14500 | 11300 | 10400 | 12600 | 0.4-0.6 | 12T |
| 20-30T | 18000 | 10000 | 8000 | 17300 | 13000 | 17200 | 14000 | 0.4-0.7 | 12T |
| 35-40T | 20000 | 11000 | 9000 | 19200 | 14900 | 12900 | 15200 | 0.6-1.2 | 12T |
| 40-45T | 22000 | 12000 | 10000 | 21300 | 16000 | 14000 | 17000 | 0.5-1 | 20T |
| 40-50T | 24000 | 13000 | 11000 | 23000 | 17900 | 15200 | 18100 | 0.5-1.1 |
The excavator boom and stick long introduction
Long Reach is designed for maximizing digging depth and forward reach over a standard boom. It is ideal for river and sea dredging either on land or barge. The super long reach attachments enable you to achieve more digging depth compare to standard boom, maximizing efficiency at your work site. We manufacture different models of long reach which can suit a wide range of excavators ranging from 10-200 metric tons operating weight.
The excavator long boom features
Increased reach: The primary feature of an excavator long boom is its increased reach. By extending the length of the boom, excavator long booms enable operators to reach further and work in areas that would otherwise be difficult or impossible to access.
Versatility: Excavator long booms are highly versatile attachments. They can be used for a wide range of excavation tasks, from digging and grading to demolition and lifting.
Stability: Excavator long booms are designed for stability and durability. They are built with high-strength materials and are engineered to withstand the rigors of heavy-duty excavation work.
Customizable: Excavator long booms are customizable to suit the specific needs of different excavation projects. They can be equipped with various attachments, such as buckets, hydraulic breakers, and thumbs, to enhance their functionality and versatility.
Increased productivity: Excavator long booms can significantly increase productivity on the job site. With their extended reach, operators can complete excavation tasks more quickly and efficiently, reducing downtime and increasing overall productivity.
Reduced manual labor: Excavator long booms can also reduce the need for manual labor on the job site. With their increased reach and versatility, they can perform tasks that would otherwise require manual labor, saving time and reducing the risk of accidents and injuries.
The pictures of excavator long arm for CAT
