Product Details:
|
| Video Outgoing-inspection: | Provided | Marketing Type: | New Product 2020 |
|---|---|---|---|
| Warranty: | 1 Year | Application: | Excavator |
| Material: | HG785+Q355B | MOQ: | 1 Set |
| Apply To: | Universal | Usage: | Machinery Accessories |
| Delivery Time: | 15days | Operating Weight: | 1800KG |
| Moving Type: | Crawler Excavator | Color: | Customize |
| Highlight: | CAT315 Sturdy Excavator Telescopic Boom,Excavator Telescopic Boom 25m,Heavy Duty Telescopic Excavator Boom |
||
Our telescopic arm have 3 advantage
01 design advantage , there are four sliding wheels on the front,Two sliding wheels on the top , the others two on the bottom , this part separate the high pressure hose and the steel rope , to reduce grinding each other ,less grinding can prolong the service life .
02 The part advantage, the vice rope diameter is 26 millimeter , the main rope is more stronger , you can see is 30 millimeter.the sliding block, it is nylon material , it can reduce grinding,Our sliding wheel is POM Material , with high mechanical strength and rigidity
03 easy to maintain
| Excavator Ton | (A)Maximum working Length of arm | (B)Maximum digging height | Shell bucket volume(cbm) |
| 6-10T | 7600 | 10000 | 0.2-0.3 |
| 11-15T | 10500 | 14000 | 0.4-0.6 |
| 20-27T | 12500 | 16000 | 0.8-1.5 |
| 30-35T | 15500 | 20000 | 1.3-1.6 |
| 30-35T | 20500 | 25000 | 1.0-1.4 |
| 40-45T | 20500 | 25000 | 1.8-205 |
| 40-45T | 25100 | 30000 | 1.4-2.0 |
